Ganjeolgot Monitoring station

국명:간절곶감시국(KG)
The Ganjeolgot Integrity Monitoring Station plays the role of monitoring signals from Pohang, Gwangju, and Ussuriysk Transmitting Stations. Together, these make up the Korea Loran-C Chain (GRI 9930).
It uses a receiver program to calculate real-time positioning errors and conduct signal quality inspections.

Equipment

간절곶감시국 장비현황 표이며 수신기,기타장비로 구분되어있음
Receiver Other equipment
Ursanav(UN-152B) UPS, DSU, P/Supply

Monitoring Information

간절곶감시국 감시정보 표이며 위치,Control Standards(코드,SNR(dB),FLD(dB㎶),FLD(dB㎶),CSTD(㎲)),Limit(ECD,TD),비고로 구분되어있음
Location Control Standards Limit Remarks
Code SNR
(dB)		 FLD
(dB㎶)		 CSECD
(㎲)		 CSTD
(㎲)		 ECD TD
Ganjeolgot
Kanjulgot		 M
W
Z		 11
-3
-		 100
71
-		 M 1.5
W 0.2
Z
W12508.38
Z 57318.59		 ± 1.5
 ± 0.15 Ursanav(UN-152B)

Location

  • 39-2, Ganjeolgot 1-gil, Seosaeng-myeon, Ulju-gun, Ulsan
간절곶감시국 시설 이미지
